Utilize the 3D viewer located on the left-hand side of the interface to navigate through the facility.
Hover over a tag and select the corresponding button to display asset information as well as a list of drawings that matches the asset's tag name.
The GIS viewer provides an aerial view of the facility, allowing for efficient exploration of the entire site.
The white marker indicates your current location within the 3D viewer.
Click on any of the colored circles to move to that scan location.
By clicking on an asset marker pin, your position will be updated to the selected location. A list of schematic drawings will be displayed if the asset is found in the drawings database.
Use the schematic viewer to navigate through your drawings.
Utilize the pan and zoom controls to focus on specific details within the drawing.
Activate full screen mode to display the schematic on your screen.
Use the top search bar to find facility assets by tag name.
Review the search results box for Asset Classification and Tag name information of closest matches.
Select the desired asset from the resulting list to relocate the 3D and GIS views to it's location while also loading any available drawings associated to it in the Schematic Viewer
